Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.

The Archer C50 lets your PC or laptop enjoy connections 3x faster than Wireless N with Wireless AC technology. With 300Mbps over the 2.4GHz band and 867Mbps over the crystal clear 5GHz band, the Archer C50 is the superior choice for seamless HD streaming, online gaming, and other bandwidth-intensive tasks.

Innovative Antenna Design for Maximum Coverage
Four well-ordered antennas make all of your connections more efficient and stable. Advanced antenna technology increases the receiving sensitivity to enlarge Wi-Fi coverage for your home.

Easy Parental Control
Supervise children and staff with responsible access, controlled by parents or administrators. Use keywords to easily set up a blacklist and limit the level of web access.

Guest Network Access
Allow guests to join your Wi-Fi network while protecting your privacy. Make sharing easy, maintain security.

Efficient Guest Authentication with Facebook
The captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. Easily share your Facebook account to anyone who connects to your network.

Features

• Supports 802.11ac standard
• Simultaneous 2.4GHz 300 Mbps and 5GHz 867 Mbps connections for 1200 Mbps of total available bandwidth
• 4 external antennas provide stable wireless connections and optimal coverage
• Easy network management at your fingertips with TP-Link Tether
• Supports IGMP Proxy/Snooping, Bridge and Tag VLAN to optimize IPTV streaming
• Supports Access Point mode to create a new Wi-Fi access point

Specification

Wireless

• Standards: Wi-Fi 5, IEEE 802.11ac/n/a 5 GHz, IEEE 802.11n/b/g 2.4 GHz
• WiFi Speeds: AC1200, 5 GHz: 867 Mbps (802.11ac), 2.4 GHz: 300 Mbps (802.11n)
• WiFi Range: 2 Bedroom Houses, 4× Fixed Antennas, Multiple antennas form a signal-boosting array to cover more directions and large areas
• WiFi Capacity: Dual-Band, Allocate devices to different bands for optimal performance
• Working Modes: Router Mode, Access Point Mode

Hardware

• Processor: Single-Core CPU
• Ethernet Ports: 1× 10/100 Mbps WAN Port, 4× 10/100 Mbps LAN Ports
• Buttons: WPS/Wi-Fi Button, Power On/Off Button, Reset Button
• Power: 9 V ⎓ 0.85 A

Security

• WiFi Encryption: WEP, WPA, WPA2, WPA/WPA2-Enterprise (802.1x)
• Network Security: SPI Firewall, Access Control, IP & MAC Binding, Application Layer Gateway
• Guest Network: 1× 5 GHz Guest Network, 1× 2.4 GHz Guest Network

Softwares

• Protocols: IPv4, IPv6
• Parental Controls: URL Filtering, Time Controls
• WAN Types: Dynamic IP, Static IP, PPPoE, PPTP, L2TP
• Quality of Service: QoS by Device
• NAT Forwarding: Port Forwarding, Port Triggering, DMZ, UPnP
• IPTV: IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN
• DHCP: Address Reservation, DHCP Client List, Server
• DDNS: NO-IP, DynDNS


Others

• System Requirements: Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser, Cable or DSL Modem (if needed), Subscription with an internet service provider (for internet access)
  Certifications: FCC, CE, RoHS
• Environment:
  • Operating Temperature: 0℃~40℃ (32℉ ~104℉)
  • Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
  • Operating Humidity: 10%~90% non-condensing
  • Storage Humidity: 5%~90% non-condensing
• WiFi Transmission Power

  • CE EIRP: <20dBm(2.4GHz), <23dBm(5GHz),
  • FCC: <30dBm(2.4GHz & 5GHz)
• WiFi Reception Sensitivity:

  • 5GHz:

    • 11a 54M: -73dBm
    • 11ac VHT20 MCS8: -68dBm
    • 11ac VHT40 MCS9: -64dBm
    • 11ac VHT80 MCS9: -60dBm
  • 2.4GHz:

    • 11g 54M: -76dBm
    • 11n HT20 MCS7: -74dBm
    • 11n HT40 MCS7: -71dBm
